ADB Signature Series User Manual

Ferroresonant L-828/L-829 CCR Parts
 2009 ADB Airfield Solutions, Incorporated
96A0288T 7-6
All rights reserved Issued 9/04
Part Number
Description
Quantity
(6.6 A)
Quantity
(20 A)
Schematic
Referenced
Note
47A0096
Fuse, 80 A, 250 V, 240 V input, 15
kW
2
2
F1, F2
47A0097
Fuse, 90 A, 600 V, 480 V input, 30
kW
2
2
F1, F2
47A0099
Fuse, 110 A, 250 V, 208 V input only,
15kW
2
2
F1, F2
47A0101
Fuse, 175 A, 250 V, 220-240 V input,
30 kW
1
1
F1, F2
47A0102
Fuse, 200 A, 250 V, 208 V input, 30
kW
1
1
F1, F2
47A0106
Fuse, 125A, 600V 50kW
2
F1, F2
47A0108
Fuse, 1 A, 500 V, 480 V input, 7.5, 10
kW
2
2
F3, F4
47A0113
Fuse, 2 A, 250 V SLO-BLO, 208-240
V input, 4, 7.5, 10, 15, 20, 30 kW
2
2
F3, F4
47A0119
Fuse, ½ A, 250 W, SLO-BLO, 4, 7.5,
10, 15, 20, 30 kW
See note.
See note.
F5, F6
A
47A0141
Fuse, 200A, 600V 70kW
2
F1, F2
47A0187
Fuse, 3 A, 500 V, SLO-BLO, 480
input, 15, 20, 30 kW
2
2
F3, F4
49A0081
Fuse holder, 30 A, 600 V, 480 only, 4,
7.5, 10 kW
1
1
F1, F2
49A0082
Fuse holder, 60 A, 600 V,
480 only, 15, 20 kW
1
1
F1, F2
49A0084
Fuse holder, 30 A, 600 V, 4, 7.5, 10,
15, 20, 30 kW
1
1
F3, F4
49A0085
Fuse holder, 100 A, 600 V,
480 only, 30 kW
1
1
F1, F2
49A0091
Fuse holder, 240 V, 100 amp,
240 V, 15 kW
1
1
F1, F2
49A0097
Fuseblock, 101-200A, 600V
1
F1, F2
52A0099
Ammeter, 0-10 amps, L-828, 6.6 A
regulators only
1
1
Ammeter
52A0098
Ammeter, 0-25 amps, L-828, 20 A
regulators
Ammeter
53A0331
Cont 3P, 200A, 170A 120Vac Coil
70kW
1
K1
53A0412-40
Contactor, 2-pole, single-phase, Class
42, 600 Vac maximum, 110-120 V
coil (for 480 V input only)
1
1
K2
L-828/L-829 CCR General
Assembly Parts List (contd.)
