114 Adria Caravans
To switch off, turn the control knob clockwise to the "0 position".
The flame goes out and the flame safety device automatically shuts off the gas supply.
Close the quick-action stop valve (Fig. 69/3).
For more information, see the separate instructions from the manufacturer.
14.3 Extractor hood (special equipment)
The extractor hood is located above the gas stove.
Using the extractor hood:
Use the rocker switch (Fig. 91/2), (Fig. 92/2) to switch on the extractor hood during cook-
ing (Fig. 91/1), (Fig. 92/1). This prevents condensing water vapour and unpleasant
odour in the vehicle.
On some vehicles, you can switch on the lighting of the cooking area with the rocker
switch (Fig. 92/3) on the extractor hood.
For more information, see the separate instructions from the manufacturer.
Fig. 91 Extractor hood - version 1
1 Extractor hood
2 Rocker switch
Fig. 92 Extractor hood - version 2
1 Extractor hood
2 Extractor hood rocker switch
3 Lighting rocker switch
