Before the journey
5
16 Adria Caravans
 Check that all corner steadies have been fully raised.
 Check the caravan lights when the towing vehicle is coupled.
5.2.1 Couplings
5.2.1.1 Couplings AK 150 V/160/200 V/251 S/300
The coupling mechanism has an "open" position which means the coupling remains open until
the tow ball locks completely into the cup.
Coupling the vehicle:
 Check that the coupling is open.
 Position the open coupling Fig. 1) onto the tow ball of the towing vehicle until it fully
engages with a click.
 To help, press the coupling grip (Fig. 1/2) down by hand.
 Check that the safety marking (green band) (Fig. 1/1) is visible.
For more information, see the separate instructions from the manufacturer.
Warning!
Risk of weaving
 Before coupling, make sure the tow ball on the towing vehicle is free from oil and
grease.
 Clean off any dirt before coupling.
Fig. 1 Couplings AK 300 and AK 160
1 Safety marking
2 Coupling grip
10100016
1
2
