15.1.3 Dometic 8 series with manual mode selection and automatic

ignition MES

15.1.4 Dometic 8 series with manual mode selection and battery igni-

tion.

Fig. 97 Refrigerator controls (Dometic 8 series)

1 On/Off / energy selector button

2 "Malfunction" LED indicator

3 "Mode" LED indicator

4 "Temperature range" LED indicator

5 Temperature setting switch

Fig. 98 Refrigerator controls (Dometic 8 series)

1 Power selector switch "Off"

2 Power selector switch "Gas mode"

3 Power selector switch "12 V"

4 Power selector switch "230 V"

5 Temperature controller

6 Battery ignition (gas mode)

7 Flame display (gas mode)

1 5432

10100032

21 3 4

5 6 7
