Adria caravan - Swinging the Table Foot Down; Lowering the Telescopic Table

GB
Sleeping arrangements
9
66 Adria Caravans
 Press the locking button (Fig. 52/2) to unlock the table foot (Fig. 52/1).
 Swing the table foot down 90°.
 Then place the table in the bottom position against the seat.
9.2.2 Lowering the telescopic table
 Hold the table top with one hand in the middle of the table
 Turn the locking lever (Fig. 53/1) to the left with the other hand (unlocking).
 Push the table top down to the lowest position.
 Turn the locking lever (Fig. 53/1) to the right (locking).
Fig. 52 Swinging the table foot down
1 Table foot
2 Locking button
Fig. 53 Lowering the telescopic table
1 Locking lever
1
2
10100020
1
