8.3.3 Permanent ventilation
Setting the window to the "permanent ventilation" position
 Open the locking levers as described in Chapter 8.3.2.
 Pull the window back until it is almost closed.
 With a locking lever (Fig. 17/1) with securing button, make sure the latch plate
(Fig. 17/2) fits properly in the fork (Fig. 17/3) when closing the lever (Fig. 17/1).
 With a locking lever (Fig. 17/1) without securing button, make sure the locking catch
(Fig. 17/4) fits properly in the recess of the locking plate (Fig. 17/2) when closing the
lever (Fig. 17/1).
Caution!
Cracks in the window
 Close only the levers (Fig. 15/2) at the bottom edge of the window in the "permanent
ventilation" position, otherwise the window pane is bent. This could result in the forma-
tion of cracks in the acrylic glass window.
 Ensure all bottom catch bars are closed in the same position, otherwise, the window
could be distorted.
Fig. 17 Hinged window in permanent ventilation posi-
tion
1 Lever
2 Latch plate
3 Fork
4 Locking catch
2 13
4
