10.7 Electrical diagrams for 12 V supply from towing vehicle
Tab. 7 Legend, function of 12 V towing vehicle supply
Tab. 8 Legend, colours of 12 V towing vehicle supply
No. Function Type
A1 Brake light and rear light PY21/5W
A2 Reversing light P21W
A3 Rear fog light P21W
A4 Direction indicator PY21W
B1/B2 License plate light C5W
E Contour light, red/white W5W
E1 Side marker light - orange LED
F1/F2 Contour light, front - white LED
M 3rd brake light LED
N Earth connection
O Caravan charging station, power supply unit
U Connector plug for towing vehicle
No. Colour No. Colour
01 Black 19 Blue - white stripe
02 Red 21 White - blue stripe
03 Green 23 Green - red stripe
04 Blue 24 Lilac - white stripe
05 White 25 Orange - black stripe
06 Brown 26 Green - blue stripe
07 Yellow 27 White - black stripe
08 Lilac 28 White - red stripe
09 Grey
12 Pink
13 Orange
