8.5.5 Roof hood blind and insect screen running in opposite direc-
tions
The blind (Fig. 27/2) and the insect screen (Fig. 27/3) are fitted in the inner frame (Fig. 27/1)
of the roof hoods.
Opening/closing the blind or insect screen:
 Reach into the recess of the end bar of the blind (Fig. 27/2) or insect screen (Fig. 27/3).
 Slide to the desired position.
Important!
• Both are continuously adjustable and can be operated together or separate from each
other.
• Only close the blind to a maximum of 75% during direct sunlight. Air must be able to cir-
culate.
Fig. 27 Roof hood blind and insect screen running in
opposite directions
1 Inner frame
2 Blind
3 Insect screen
1
3
2
