126 Adria Caravans
16.1 Toilet system
16.1.1 Thetford Cassette C-200 S and C-260 S
Before use:
Turn the toilet bowl to the desired position using both hands.
Before flushing, use the lever (Fig. 101/1) to open the valve blade.
To activate the control panel, press the flush button (Fig. 101/3) once.
Run some water into the bowl by pressing the flush button again briefly.
After use:
Push the lever (Fig. 101/1) to the side if the valve blade is still closed.
Flush the toilet (Fig. 101/3) by pressing the flush button for several seconds (if neces-
sary, reactivate the control panel (Fig. 101/2).
Close the valve blade with the lever (Fig. 101/1) after flushing.
For more information, see the separate instructions from the manufacturer.
Fig. 101 Thetford C-200 S and C-260 S
1 Lever for opening the valve blade
2 Operator panel
3 Flush button
4 Waste level indicator
5 Automatic ventilator (special equipment)
