10.6 Electrical diagrams 230 V
See the following electrical diagrams for the exact layout of the electrical components and wir-
ing.
These diagrams are required for possible repairs and maintenance.
Tab. 6 Legend for the following electrical diagrams for 230 V installation
Caution!
Damage to the electrical system
 Have maintenance and repair work performed by an authorised workshop.
 Improper maintenance and repair work voids your warranty claims.
A Power input 220-240 V, 16 A, 2P+T
B Main fuse with FI 220-240 V, 25 A, 0.03A
B1 Circuit breaker 220-240 V, B16A
B2 Circuit breaker 220-240 V, C10A
B3 Circuit breaker 220-240 V, C10A or B16A
C Junction box
D Socket with earth contact 220-240 V
E Refrigerator
F
Protective earthing (H07V-K) 4mm
2
G Heater/boiler
H Boiler switch (TRUMA THERME)
I Air-conditioner, pre-installation (roof top)
/// 3-wire cable (H05VV-F)
