8.3.2 Opening/closing the windows
To open and close the hinged windows, open or close all locking levers on the respective
hinged window.
Opening the window:
 If the locking lever has a securing button (Fig. 16/1), press and hold down the securing
button.
 Turn the lever (Fig. 16/2) to the middle of the window.
 Open all window locks.
 Open the window.
Closing the window:
 Close the window.
 If the locking lever has a securing button (Fig. 16/1), press and hold down the securing
button.
 Turn the lever (Fig. 16/2) to the window frame.
 The fork (Fig. 16/4) of the lever (Fig. 16/2) closes completely on the inside of the latch
plate (Fig. 16/3).
Fig. 16 Opening and closing the hinged windows
1 Securing button
2 Lever
3 Latch plate
4 Fork
5 Locking catch
3 24 15
