Adria caravan - Coupling AKS 3004

GB
Before the journey
5
18 Adria Caravans
5.2.1.3 Coupling AKS 3004
Coupling the vehicle:
 Move the stabilizer lever up (Fig. 3/2) to the top position.
 Pull the coupling grip (Fig. 3/3) upwards and open the coupling.
 Position the open coupling onto the tow ball until the coupling grip locks in with a click.
The coupling grip moves back to the start position on its own.
 To help, press the coupling grip (Fig. 3/3) down by hand.
 Check that the safety marking (green band) (Fig. 3/1) is visible.
 Press the stabilizer lever (Fig. 3/2) down to the lowest position.
For more information, see the separate instructions from the manufacturer.
Fig. 3 Coupling AKS 3004
1 Safety marking
2 Stabilizer lever
3 Coupling grip
10100111
3
2
1
