Adria Caravans 31
Opening / closing the door:
Push the door handle (Fig. 13/1) down and open the door.
When released, the door handle (Fig. 13/1) returns to its initial position.
To close the door, pull the door handle (Fig. 13/1).
Locking the door:
Pull the door handle (Fig. 13/1) upwards into locking position (Fig. 13/2).
The door is locked and can be opened from the outside only with the key.
Separating/locking the two-part door (special equipment):
Close the door.
Turn the locking latch (Fig. 13/3) to horizontal position (Fig. 13/4).
The upper part of the door is unlocked and the lower part of the door is locked at the
same time.
Turn the locking latch (Fig. 13/3) to vertical position again for opening.
8.1.3 Door arrester
Releasing the door arrester
Pull the holder (Fig. 14/3) at the holder part (Fig. 14/2) of the door arrester.
Pull the door part (Fig. 14/1) with the door out of the holder part.
Fig. 13 Opening / closing the entrance door from the
inside
1 Door handle (door unlocked)
2 Door handle (door locked)
3 Locking latch
Fig. 14 Door arrester, 2-part
1 Door part
2 Holder part
3 Holder
