Living in the caravan
8
44 Adria Caravans
8.5.6 Roof hood blind and insect screen running in the same direc-
tion
The blind (Fig. 28/2) and the insect screen (Fig. 28/1) are fitted in the inner frame of the roof
hood.
Opening/closing the blind or insect screen:
 Press the two halves of the grip of the blind (Fig. 28/2) or insect screen (Fig. 28/1)
together.
 Slide to the desired position.
Important!
• Both are continuously adjustable and can be operated together or separate from each
other.
• After releasing the grip, the blind is automatically clamped into place in the inner frame of
the roof hood.
• Only close the blind to a maximum of 75% during direct sunlight. Air must be able to cir-
culate.
Fig. 28 Roof hood blind and insect screen running in
the same direction
1 Insect screen
2 Blind
1 2
