8.3.4 Sliding windows (special equipment)
Opening the sliding window:
 Press the handle (Fig. 18/2).
 Slide the window (Fig. 18/1) to the side.
Closing the sliding window:
 Push the window (Fig. 19/1) until it is closed and the handle (Fig. 19/2) latches into place
in the catch (Fig. 19/3).
Fig. 18 Opening the sliding window
1 Window
2 Handle
Fig. 19 Closing the sliding window
1 Window
2 Handle
3 Catch
1
2
1
3
2
