Adria caravan - Dometic 7 Series with Automatic or Manual Mode Selection System

GB
Refrigerator & freezer
15
120 Adria Caravans
Opening the refrigerator Dometic 8 series:
 Press the unlock button (Fig. 95/1) down and open the refrigerator door.
Closing the refrigerator Dometic 8 series:
 An automatic lock is fitted on the refrigerator door. When you close the refrigerator door
and press it on firmly, the door locks automatically.
Locking Thetford refrigerators:
 An automatic lock is fitted on the refrigerator door. When you close the refrigerator door
and press it on firmly, the door locks automatically.
15.1.2 Dometic 7 series with automatic or manual mode selection
system
Fig. 95 Refrigerator lock Dometic 8 series
1 Unlock button
Fig. 96 Refrigerator controls (Dometic 7 series)
1 Frame heater switch
2 On/Off / energy selector button
3 Dimmer for LED indicator (accessible only when the door is open)
4 Gas / electric thermostat
10100033
1
3 421
