128 Adria Caravans
16.1.3 Water tank toilet C-402 C
The water tank holds 15 liters.
Filling the water tank:
Open the outer door (Fig. 103/1) for the cassette and water fill funnel.
Swivel the cassette emptying spout (Fig. 103/2) out about 90° and remove the water
tank extension (Fig. 107/4).
Swivel the water filling funnel (Fig. 103/3) out about 90° and unscrew the cap
(Fig. 103/4).
Position the water tank extension on the water filling funnel.
Observe the water level in the tube (Fig. 103/5) and fill with water up to just under the
water filling funnel.
Remove the water tank extension.
Screw the cap (Fig. 103/4) back on and swivel the water filling funnel (Fig. 103/3) back
in.
Store the water tank extension (Fig. 107/4) on the cassette and swivel the emptying
spout of the cassette (Fig. 103/2) back in.
Close the outer door (Fig. 103/1).
For more information, see the separate instructions from the manufacturer.
Fig. 103 Water tank toilet C-402 C
1 Outer door
2 Cassette emptying spout
3 Water filling funnel
4 Water filling funnel cap
5 Water level indicator
