4-40 ADS TRITON+
®
Manual
Edit the data delivery device in the following way:
PRISM
z Server Enter IP address 13.82.147.226 to deliver data to the
ADS database at the user selected intervals.
z Normal Select the data delivery rate for non-alarm conditions
z Fast Select the data delivery rate to use to deliver data to the
ADS database when alarm conditions exist at the monitor. Data
delivery will continue at this interval until the alarm conditions
return to normal.
FTP Setup 1/ FTP Setup 2
z Mode Select either Active or Passive to configure the manner
of communication with the FTP site. Passive is the
recommended selection.
z Normal Select the rate at which you want the monitor to
upload data to the selected destination during non-alarm
conditions. Determine the appropriate interval based on the
sample rate for the monitor and the number of entities for
which the monitor records data. A faster sample rate and/or a
greater number of entities may require a more frequent interval
for data delivery.
x Fast Select the interval at which you want the monitor to
upload data to the selected FTP destination while under alarm
conditions.
z Server Enter the IP address or URL of the FTP site to which
you want the monitor to send the data.
z Folder (optional) Enter the name of the folder at the FTP
site to which you want the monitor to upload the data. If this
field is left blank, files will be delivered to the root folder.
Note: Qstart
XML
does not create a folder automatically.
Therefore, if you want the monitor to deliver the data to a
specific folder, you must create the folder through the FTP
site manually before the monitor begins uploading data to
the site. For successful data delivery, folder names on the
