ADS TRITON+ - Appendix A Specifications; TRITON+ Flow Monitor (ADS P;N 8000-FST-IM

A-1
A P P E N D I X A
Specifications
This appendix contains specifications for the ADS TRITON+
£
flow
monitor and associated subassemblies, sensors, cables, and the
external power, Modbus, I/O, and landline hardware.
TRITON+ Flow Monitor (ADS p/n 8000-FST-IM)
Enclosure
Cylindrical 0.37
-inch (6.39-
mm) thick, seamless,
plastic canister with stainless steel threaded
inserts
Aluminum end
-cap attached to canister with
four
stainless steel bolts and a gasket interface
Meets NEMA6P/IP68 standard
Dimensions
17.75 inches (451 mm) long by 8.75 inches (222
mm) maximum diameter 6.63 inches (168 mm)
minimum diameter
Weight
30.3 pounds (13.7 kg) (with 12
-
volt battery pack)
Operating /
Storage
Temperature
Operating:
-4q to 140q F (-20q to 60q C)
Storage:
-4q to 167q F (-20q to 75q C)
