ADS TRITON+ - Intrinsically-Safe Sensors

A-6 ADS TRITON+ Manual
Intrinsically-Safe Sensors
AV|Gated Sensor (ADS p/n 8K-CS7-10-35)
This sensor supports upward ultrasonic depth, average velocity,
pressure depth, and measurement of water temperature.
AV|Gated Sensor
Housing
Polycarbonate plastic shell, epoxy-filled
Dimensions
Enclosure: 6.76 inches (172 mm) long x 1.23
inches (31 mm) wide x 0.83 inches (21 mm) high
Cable
Standard size: 35 feet (10.7 m) x 0.28 inches (7.2
mm) nominal OD, polyurethane jacket
Extension cables available up to 300 feet (91.4 m)
Operating /
Storage
Temperature
Operating:
-4q to 140q F (-20q to 60q C)
Storage
: -4q to 167q F (-20q to 75q C)
Note:
This sensor will not produce accurate
readings in frozen flow.
Upward Ultrasonic Depth
Upward Depth
Accuracy
0.5% of
reading or +/- 0.125 inches (3.2 mm),
whichever is greater
Deadband
Extending 1.0 inch (25 mm) up from the
bottom
of
the sensor
Frequency
1 MHz
Range
72 inches (1828.8 mm)
Resolution
0.01 inches (0.25 mm)
Drift
0
