A-24 ADS TRITON+ Manual
XIO (ADS p/n 8000-0400)
The XIO
™
(External Input/Output unit) enables the TRITON+ to
receive power from an AC power source and serves as a digital and
analog input and output interface.
XIO
Enclosure
Indoor/outdoor NEMA 4X (IP 66), PBT and
polycarbonate plastic with hinged cover
Dimensions
11.02 inches (280 mm) long x 7.49 inches (190
mm) wide x 5.03 inches (128 mm) deep
Weight
5.0 pounds (2.3 kg)
Operating/
Storage
Temperature
14
q to 122q F (-10q to 50q C)
Power Supply
XP Power DNR60US24 (
Refer to page A-22 for
specifications and details on the power supply)
Power Input
85
-264 VAC, 120-375 VDC; 47-
63 Hz; 1.10 A @
110 / 0.59 A @ 250 VAC
Analog Inputs
Two 4
-20mA inputs
Isolation: 1500 VAC
Accuracy: 0.05% F.S.
Thermal Drift: 100ppm/C
Analog Outputs
Two 4
-20mA outputs
Provides loop power
500 ohm drive capability
Isolation: 1500 VAC
Accuracy: 0.1% F.S.
Linearity: 0.05% F.S.
Thermal
Drift: 100ppm/C
