D-2 ADS TRITON+ Manual
Telog Ru-33 or Ru-35
Using a wireless, battery-powered TRITON+ monitor to support
the Telog Ru-33 or Ru-35 requires some limited configuration and
setup of the TRITON+. These procedures involve designating the
appropriate identification information to enable recognition and
data exchange between the ADS and Telog or Ayyeka units and
using an interface cable to connect the monitor to the RTU.
Note: The Telog Ru-33 and Ru-35 must have firmware
version 3.300 or later to effectively request data from the
TRITON+ monitor. Contact Telog customer support for
information on setting up the Ru-33 or Ru-35.
Connecting the units together primarily involves running the ADS
Triton-Telog Comm Cable from the battery-powered Ru-33 or Ru-
35 to the battery-powered TRITON+ monitor. This application
requires installing both units in the manhole, a hazardous
environment. However, ADS offers an optional extension cable
(ADS p/n 8000-0044-25) that allows you to install the Telog unit
outside the hazardous environment.
Note: The Telog Ru-33 and Ru-35 do not possess IS
(intrinsically-safe) certification. Therefore, an installation
involving connecting the Telog to the IS TRITON+ with
both units residing inside the manhole will not be
considered intrinsically safe. The installation will be
considered intrinsically safe only when the Ru-33 or Ru-
35 is installed outside the manhole.
Configuring the Monitor to Support the Ru-33 or
Ru-35
Configuring the TRITON+ to support the Telog Ru-33 or Ru-35
requires setting two parameters in Qstart
XML
when establishing a
new location. Refer to Create and Configure the Monitor Location
in Chapter 4, Configuration and Activation, for more information.
x Modbus ID This represents the Modbus slave ID that will be
used by the Ru-33 or Ru-35 to indicate the specific monitor
