ADS TRITON+ - USB Serial Interface (ADS P;N 8000-0337

A-20 ADS TRITON+ Manual
Accuracy
+/- 0.25º between 0 and 40º
Resolution
0 to 60
º = 0.03º;
60 to 90
º = 0.3º
Mounting Method
Mount vertically (90
º) or horizontally (180º) or
level on flat surface on the closed flood gate
Compatibility
The
I
nclinometer sensor is ONLY compatible with
the ADS
TRITON+ flow monitor via the
communications port
USB Serial Interface (ADS p/n 8000-0337)
The USB serial interface (or direct connection) cable supports on-
site communications with the ADS TRITON+ monitor. It consists
of two cables: a primary cable with interface box and potted metal
connector and a standard USB Type A to Type B cable.
USB Serial Interface Cable
Cable Length
Primary Cable: 10 feet
(3.1 m) long
USB A
-to-B Cable: 6 feet (1.8 m) long
Construction
Primary: Shielded, 10
-conductor cable with
polyurethane jacket; in
-line opto-isolation
PCB in ABS plastic housing : 3.3 inches (85 mm)
x 2.5 inches (63 mm) x 1.1 inches (28 mm)
Connections
Primary: Factory
-fitted potted connector (to
TRITON+
monitor COMM + EXT PWR port)
USB A
-to-
B Cable: Type B connector (to interface
box) and Type A connector (to USB port on
computer)
