ADS TRITON+ - Page 491

Specifications A-19
Accuracy
0.125 inches (3.2 mm)
Deadband
1.0 inch (25.4 mm) from the sensor face or 5% of
maximum range, whichever is greater
Frequency
40 kHz
Range
1.0 inch (25.4 mm) (or 5% of maximum range,
whichever is greater) to 10.0 feet (3.05 m)
Resolution
0.01 inches (0.25 mm)
Drift
0.0 inches/mm
Inclinometer Sensor (ADS p/n 8K-0528)
This sensor determines tilt via an accelerometer.
Inclinometer Sensor
Housing
Solid, molded ABS providing high impact and
abrasion resistance in a fully sealed device
Dimensions
Height
0.865 in (2.2 cm); Width: 2.03 in (
5.16 cm);
Length:
3.0 in (7.62 cm)
Cable
25 ft (7.62 m) X 0.28 in (7.1 mm) OD;
polyurethane jacket
Weight
1.5 lbs (
0.68 kg) including 25 feet (7.62 m) of
communication cable and connector
Operating Range
0 to 90
º
Operating /
Storage
Temp
erature
Operating:
-4q to 140q F (-20q to 60q C)
Storage:
-4q to 167q F (-20q to 75q C)
Note:
The sensor will not produce accurate
readings when ice is built up on the sensor.
