A-18 ADS TRITON+ Manual
Surcharge Pressure Depth
Pressure
Range
0.0 to 5.0 PSI
(0.0 - 0.34 Bar): up to 11.5 feet (
3.5
m)
0.0 to 15.0 PSI (0.0
-
1.03 Bar): up to 34.5 feet
(10.5 m)
0.0 to 30 PSI (0.0
– 2.07 Bar): up to 69.0 feet
(21.0 m)
Pressure
Accuracy
0
- 5.0 PSI (0 - 0.34 Bar): +/- 1.4 inches (36 mm
)
0
- 15.0 PSI (0 - 1.03 Bar): +/- 4.1 inches (104
mm)
0
- 30 PSI (0 - 2.07 Bar): +/-
8.3 inches (211 mm)
Pressure
Resolution
0.01 inches (0.25 mm)
Ultrasonic Depth Sensor (ADS p/n 8K-CS5-D1-00-
30)
This sensor supports downward ultrasonic depth.
Ultrasonic Depth Sensor
Housing
ABS plastic shell, epoxy-filled
Dimensions
10.61 inches (269 mm) long x 2.03 inches (52
mm) wide x 2.45 inches (62 mm)
high
Cable
Standard size: 30.0 feet (9.14 m) long x 0.35
inches nominal
(8.9 mm nominal) OD,
polyurethane jacket
Extension cables available up to 300 feet (91 m)
Operating /
Storage
Temperature
Operating:
-4q to 140q F (-20q to 60q C)
Storage:
-4q to 167q F (-20q to 75q C)
Note:
The sensor will not produce accurate
readings when ice is built up on the sensor.
