ADS TRITON+ - Expac (ADS P;N 8000-0377

Specifications A-21
ExPAC (ADS p/n 8000-0377)
The ExPAC (External Power and Communication unit) enables the
TRITON+ to receive power from an external DC source and
supports Modbus communications.
ExPAC
Enclosure
Rectangular, ABS Plastic, DIN rail or wall mount,
IP20
Dimensions
5.7 inches (145 mm) wide x 3.6 inches (91 mm)
high x 1.6 inches (41 mm) deep
Weight
0.55 pounds (0.25 kg)
Operating
Temperature
-4
q to 122q F (-20q to 50q C)
External Power
Requires DC power input between 9 to 36 volts
and a minimum of 15 watts
I.S. DC output of
8 to 11.8 volts, 500 mA
Connectors
One RS
-485 (3 terminals), one RS-232 (DB9),
one USB type B, one 9
-to-36-volt DC input (3
terminals), monitor communications (5 terminals),
and one DC
out (3 terminals)
Certifications
Associated Apparatus certification for use with
approved equipment in Zone 0 (
equivalent to
Class I, Division 1, Groups C & D, in the U.S.) and
Zone 0 in the EU via SIRA/ATEX
/CSA/UKCA
Sira 09ATEX2027X, IECEX
SIR09.0020X,
CSA
13CA2671180X, UKCA CSAE
22UKEX1159X
