9-16 ADS TRITON+ Manual
Digital Outputs
The TRITON+ (with an ADS XIO) can provide the event status for
to up to two third-party systems or devices via digital (relay) output
signals. To configure the monitor to properly deliver the signals to
these third-party devices, you must configure the ADS Qstart
XML
software with the specific event about which you want to relay the
current status information.
Connecting a Third-Party Device to a Digital
Output on the XIO
Perform the following procedure to connect each third-party device
(up to two) to a digital output terminal on the ADS XIO:
Note: Make sure external power is available, but not
turned on, to the monitor before connecting the signal
wiring. If it is not available, you cannot complete testing,
which may require return visits by the owner
representative and/or electrician or instrument technician
for wiring problems.
1. Configure the Digital Ouput 1 (or 2) component of the XIO
Device through Qstart
XML
to indicate the event with which you
want to associate each digital output. Refer to Chapter 4,
Configuration and Activation, for instructions on selecting this
parameter in Qstart
XML
.
