ADS TRITON+ - I;O and Modbus Capability; Analog Inputs and Outputs

System Overview 2-35
I/O and Modbus Capability
The TRITON+ supports several different inputs and outputs
through the ADS XIO interface unit. The monitor facilitates
Modbus communications through the ADS ExPAC or ADS XBUS.
Inside of XIO showing I/O terminal block, power supply, and ExPAC
Analog Inputs and Outputs
The monitor can support up to two 4-20mA analog inputs and two
4-20mA analog outputs. The analog output capability may be used
to provide information or signals to third-party systems, such as
monitors from other vendors. The TRITON+ sends out information
through the outputs at the same interval used when taking sensor
readings
