4-48 ADS TRITON+
®
Manual
Targeted Select this setting in cases where ADS
temperature targets are in place such that the temperature
can be calculated based on known distances. This option
is not implemented at this time.
x Power Choose the level of power supplied to the sensor:
Auto
Select this option to allow the monitor firmware to
determine the amount of power supplied to the sensor.
This option is a function of the total range (manhole
depth). ADS recommends using the default of Auto.
This
option is selected by default.
1 to 11 Select 1 for the lowest power setting, which
would be most useful in short range installations with no
interference. Select 11 for the highest power setting, which
would be most useful in long range installations with
interference.
x Gain Control Choose the method for managing the amplification
of the analog signal that returns to the sensor:
Auto Select this option to allow the monitor to
automatically optimize the amplification of the signal.
(Recommended)
Manual Select this option to enter a fixed value between -
12db (lower amplification) and +12db (higher
amplification) at which to amplify the signal.
x Capacitance
Disable Select this checkbox to disable the
Submersion
sensor
which detects submersion when fully covered with
liquid.
Note: Disabling the Submersion sensor will also disable
SUBMERGED alarms.
Log Select this checkbox to store the Submersion sensor
readings (Capacitance) to monitor memory.
