Configuration and Activation 4-67
Surcharge Detection Select the Disable checkbox to
prevent the monitor from implementing the Surcharge
Detection function when processing Smart Depth data.
For locations that typically do not experience surcharge,
disabling Surcharge Detection eliminates the processing
time required for this function and, as a result, conserves
monitor power.
Sensor
z Physical Offset Enter the physical distance from the face of the
sensor to the crown (top) of the pipe. Refer to Chapter 5, Sensor
Installation and Connection, for instructions on measuring the physical
offset.
z Pipe Height This field displays the pipe height at the monitor
location, based on the installation table. This parameter is not editable
from this location.
z Channel Select the channel number of the port on top of the monitor
to which this device is connected.
Temperature
The temperature sensor measures the air temperature in the pipe to
apply when calculating the speed of sound in air.
Note: Under normal conditions, the parameters in the
Temperature section should not require modification.
However, if additional adjustments are necessary, refer to
the detailed description of each parameter.
z Sensor Select the source from which to measure the
temperature used when compensating for temperature in
Ultrasonic Depth Sensor readings. The channels correspond to
the sensors connected to those channels (i.e., ports) on the
monitor. The option selected here should be consistent with
the option selected for the Channel in the Sensor section to the
left of the Temperature section.
Note: The stored temperature value is the actual air
temperature reading from the Ultrasonic Depth Sensor.
