Configuration and Activation 4-101
6. View the data in tabular and graphical format on the View
Data dialog. Modify the graph based on the time period and
entities in the following ways:
7. Select the amount of data you want to display on the graph at
one time by selecting the appropriate option from the Report
Type drop-down list (All, Day, Week, or Month).
8. Limit the entities that display on the graph by clicking on the
Entities button, selecting the entities you want to display, and
clicking on the OK button. To select multiple entities, press
and hold down the Control (Ctrl) key while selecting the
individual entities. To choose consecutive entities in the list,
select the first entity you want to display, press and hold down
the Shift key, and then click on the last entity you want to
include.
9. Zoom in on a particular portion of data on the graph by
selecting the Zoom option from the Report Type drop-down
list, clicking and dragging from the top left boundary of the
data you want to view on the graph to the bottom right
boundary of the data, and then releasing.
10. Use the scroll bars on the table to navigate to the specific data
you want to view. Sort the data in the table by clicking on the
heading corresponding to the data you want to sort. Clicking
on the DateTime heading enables you to switch between
viewing the most recent and the oldest data collected from the
monitor. Clicking on an entity heading allows you to switch
between viewing the readings in descending order (beginning
with the highest value) and in ascending order (beginning with
the lowest value).
11. Close the View Data dialog when you are finished viewing the
data by clicking on the red
button at the top right
corner of the dialog.
12. Click on the green Hangup button in the Functions section to
discontinue communication with the monitor.
Qstart
XML
generates a collect log entry corresponding to the
data collect activity that includes a summary of the details
associated with the collect and general monitor status
