5-6 ADS TRITON+ Manual
bracket positioned above the crown of the pipe on the
manhole wall.
z Pipe Height and Width Measure and record the horizontal
and vertical pipe dimensions carefully. Inaccurate pipe
measurements—even slightly inaccurate measurements--can
skew and misrepresent flow data.
z Pipe Shape Taking the appropriate measurements that
precisely reflect the exact pipe shape is essential to obtaining
accurate flow calculations. Therefore, irregularly shaped pipes
will require additional measurements. Refer to the Qstart
XML
online help for more information.
Note: All relevant pipe dimensions and measurements
are required for entry in the Qstart
XML
software during
monitor configuration and activation. The software
primarily requires pipe shape, height, and width during
these activities.
z Manhole Depth Measure the distance from the rim to the
manhole invert. Distances beyond 30 feet could require
extension cables for the ParaDepth, ParaFlow, Peak Combo,
Smart Depth and Surface Combo sensors. See Appendix B.
