Sensor Installation and Connection 5-11
¼-in. (7mm x 400mm) anchor cable ties
18-inch (457-mm) stainless steel crank handle
1
Models 8000-FST-IM-4WW-XXX include the 12-volt battery pack; Models 8000-
FST-IM-EP-4WW-XXX (for external power) do not include the battery pack.
2
IS pressure depth transducers (indicated by —xx- in the part number) are available
in Peak Combo Sensors and Surface Combo Sensors in 0 — 5 psi (0 — 0.34 Bar), 0
— 15 psi (0 – 1.03 Bar), and 0 — 30 psi (0 — 2.07 Bar) pressure ranges. Example:
a Peak Combo Sensor with a 0 – 15 psi (0 – 1.03 Bar) pressure transducer would be
specified in psi: 8K-CS4-15-35.
3
Extension cables can be ordered to specific lengths up to 300 ft. (91m). Note the
desired length (in feet) in the –xxx portion of the part number. Standard lengths are
10 ft. (3.0m), 25 ft. (7.6m), 50 ft. (15.2m), 75 ft. (22.8m), 100 ft. (30.5m), 125 ft.
(38.1m), 150 ft. (45.7m), and 200 ft. (61.0m). All other lengths must be custom
ordered.
4
The external power/communications cable and the ground cable included in the
external power grounding kit can be ordered to specific lengths up to 800 ft. (243m).
Note the desired length (in feet) in the –xxx portion of the part number. Standard
lengths are 10 ft. (3.0m), 25 ft. (7.6m), and 100 ft. (30.5m). All other lengths must
be custom ordered.
Gathering Tools and Equipment
Gather the following tools for the installation:
z Battery-powered hammer drill with assorted bits – including
the following at a minimum:
¼-inch (6-mm) x 6-inch (150-mm) masonry bit
3/8-inch(10-mm) x 4-inch (100-mm) [minimum length]
masonry bit
5/16-inch (8-mm) carbide-tipped bit
z Heavy 4-pound (1.5-Kg) hammer
z Rubber mallet
z 24-inch (610-mm) carpenter’s level
z Nut driver or socket set (English plus 13-mm for canister
hardware)
