5-62 ADS TRITON+ Manual
Gathering Parts and Supplies
Gather the following equipment for the installation:
x Grade Pole
x J-Hook
x Folding Carpenter’s Rule with a brass slide
x 36-inch (914-mm) Carpenter’s Level
Obtain the following supplies from ADS before performing the
Long Range Depth Sensor installation to prevent any costly delays.
When ordering, specify the TRITON+ monitor Long Range Depth
Sensor installation hardware. In addition, please indicate the type
of mounting hardware desired for mounting the monitor: mounting
bracket (wall/rim mount) or hook (rung mount).
Quantity
Description
ADS P/N
1
TRITON+
flow monitor (
battery or externally-
powered)
8000-FST-IM-
4WW(
-XXX),
8000-
FST
-IM-EP-
4WW(-
XXX)
1
Monitor mounting bracket/flange (for mounting
monitor to manhole rim or wall)
I40–0009
3
Monitor mounting bracket bolt, hex, SS, M8 X
30mm
508058
3
Monitor mounting bracket washer, flat, SS
517-8001254-00
3
Monitor mounting bracket washer, lock, SS
517-8001274-00
1 as
needed
Hook, SS, 2-piece w/ hardware
(for hanging monitor on manhole rung;
Alternative to I40-0009)
8000-0021
1
Long Range Depth Sensor
8K-CS6-C1-10
1 as
needed
Mounting Bar
8000-0450
1 as
needed
Extension Rod
8000-0481
1 as
needed
Wall Mount
8000-0484
1 as
needed
IS Standard or Custom Sensor Extension Cable
for Long Range Depth Sensor
8000-0023–xxx
2
