5-74 ADS TRITON+ Manual
4. Double-check that the bar is suspended tightly at anchor points.
Long Range Sensor Fully Installed
Installing the Submersion Sensor on Manhole
Frame
Attach the Submersion Sensor to the manhole frame as close to the
top of the rim as possible. The Submersion Sensor senses when
flow depths reach it and will cause the TRITON+ to send out a
Submerged alarm when the sensor goes under water.
Make sure the
wire from the
Submersion
Sensor is
hanging from
the bottom of
the sensor
