Sensor Installation and Connection 5-81
Gathering Parts and Supplies
Gather the following parts and supplies before heading to the field to
install the ADS Topside Retrieval System along with either the
ParaDepth or ParaFlow sensor.
Gather the following equipment for the installation:
x Battery powered hammer drill
x
3
8
ൗ
” Masonry Bit
x 4-lb. Hammer
x
9
16
ൗ
” Nut Driver or Deep Well Socket & Wrench
x 12-inch (305-mm) Carpenter’s Level
x Small Phillips Blade screwdriver
x Diagonal Wire Cutters
x Folding Carpenter’s Rule with Brass Slide
NOTE: Tools are listed in standard (SAE) sizes. Select
equivalent metric (SI) tools as needed.
All anchor bolts, nuts, and washers must be stainless steel.
Obtain the following supplies from ADS before performing the
Topside Retrieval System installation to prevent any costly delays.
The list below only covers the retrieval system; it does not include
monitor installation parts and supplies.
KIT, SYSTEM, MOUNTING BRACKETS,TOP-
SIDE (includes
Wall Mount Bracket, Sensor
Bracket and Hardware Kit)
TOOL, RETRIEVAL, EXTENDABLE, 4-
SECTION, ALUMINUM (Retrie
removing and re-
installing the ParaDepth or
ParaFlow Sensor on the Wall Mount Bracket
from street-level)
