Sensor Installation and Connection 5-87
Stainless Steel Nuts and Washers Behind Mounting Bracket Tab for Leveling
Purposes
NOTE: In situations where the manhole wall surface is
inconsistent/uneven, run stainless steel nuts onto the top
and bottom Lag Bolts followed by stainless steel washers
before placing the bracket on the bolts. Adjust the nuts
behind the bracket to more easily level the bracket front to
back.
10. Attach the ParaDepth/ParaFlow sensor to the Sensor Bracket
taking care that the sensor is properly oriented for the position
of the Wall Mount Bracket.
