External Power 6-19
Connect the wires to the power supply and the ExPAC in the
following way:
1. Strip the individual wires on both ends to prepare for
connecting to the terminals on the hardware.
2. Loosen the screws on one of the –V and one of the +V DC
output terminals (front, top corner) on the power supply.
DC output terminals on power supply
DC OK
+V
-V
DC OUTPUT TERMINAL
CONNECTIONS
POWER SUPPLY
