10-12 ADS TRITON+ Manual
A typical message exchange, asking for the first 10
registers, would occur as follows:
000064-Tx:3A 30 35 30 33 30 30 30 30 30 30 30 41 45 45 OD
OA
000065-Rx:3A 30 35 30 33 31 34 30 30 30 30 43 32 43 36 30
30 30 30 43 32 43 36 30 30 30 30 43 32 43 36 38
45 33 39 43 32 39 31 30 30 30 30 43 32 43 36 41
41 OD OA
Des
cription
Qstart
XML
Entity
Standard Units of
Measure
Registers
Peak Velocity
from Peak
Combo Sensor
or Velocity from
AV|Gated
PEAKVEL_1
for
Peak Combo or
VELOCITY for
AV|Gated
Feet
per Second
4000
1-40002
Upward
Ultrasonic Depth
from Peak
Combo
or
AV|Gated
Sensor
UPDEPTH_1
Inches
40003
-40004
Pressure Depth
from Peak
Combo
or
AV|Gated
Sensor
PDEPTH_1
Inches
4000
5-40006
Water
Temperature
from Peak
Combo
or
AV|Gated
Sensor
WATERTEMP_1
Fahrenheit
4000
7-40008
Surface Velocity
from Surface
Combo Sensor
SURFACEVEL_3
Feet per Second
40017
-40018
