11-72 ADS TRITON+ Manual
Problem
Data or readings received at customer input device from
XIO 4
-20 mA output are not accurate or were
unexpected.
Possible
Causes
Wiring from XIO output to external 4
-
20 mA input device
may not be properly connected. (
Note: The XIO
provides loop power to both 4
-20 mA outputs).
XIO Device
may not have been properly configured
through
Qstart
XML
.
Analog module in XIO may not have been setup properly
or may be defective.
Possible
Solutions
Verify wiring between XIO output and the external input
device has been properly connected.
Verify that the correct entity has been selected and that
the scale has been set properly in
Qstart
XML
. If
necessary, adjust the configuration and reactivate the
monitor.
Contact your regio
nal ADS representative.
