A-16 ADS TRITON+ Manual
Surface Combo Sensor (ADS p/n 8K-CS5-V2-xx-
30/1H)
This sensor supports downward ultrasonic depth, surface velocity,
surcharge peak velocity, and surcharge pressure depth.
Surface Combo Sensor
Housing
ABS plastic shell, epoxy-filled
Dimensions
10.61 inches (269 mm) long x 2.03 inches (52
mm) wide x 2.45 inches (62 mm) high
Cable
Standard size: 30.0 feet (9.14 m) long x 0.35
inches (8.9 m
m) nominal
OD, polyurethane jacket
Extension cables available up to 300 feet (91 m)
Operating /
Storage
Temperature
Operating:
-4q to 140q F (-20q to 60q C)
Storage:
-4q to 167q F (-20q to 75q C)
Note:
The sensor will not produce accurate
readings when ice is built up on the sensor.
Downward Ultrasonic Depth
Accuracy
0.125 inches (3.2 mm)
Deadband
1.0 inch (25.4 mm) from the sensor face or 5% of
maximum range, whichever is greater
Frequency
40 kHz
Range
1.0 inch (25.4 mm) (or 5% of maximum range,
whichever is greater) to 10.0 feet (3.05 m)
Resolution
0.01 inches (0.25 mm)
Drift
0
