3-2 ADS TRITON+ Manual
state, and municipal regulations concerning confined space
entry. ADS is not responsible for any injuries, damages,
claims, or liability resulting directly or indirectly from the
use of this installation guide or the installation of any ADS
equipment.
Warning: The TRITON+’s internal modem requires
connection to an external antenna. ADS recommends
using ADS antenna p/n 9000-0094 or 0096 with the
TRITON+ monitor. This antenna supports the frequencies
used by the 4WW, 4VZ and GL TRITON+ models. The
user must maintain a distance of 9 inches (229 mm)
from the antenna whenever the modem is in operation.
Note: The ADS antenna comes with two options for cable
length: 12 feet (4.39 m), ADS p/n 8000-0094, and 3 feet
(0.91 m), ADS p/n 8000-096. The shorter antenna cable
should provide better signal strength and is recommended
for use when the antenna will be installed in the manhole.
ADS TRITON+ Antenna
