ADS TRITON+ - Page 92

Communication 3-15
Installation with Antenna Cable Coiled in Manhole
11. Seal the space between the antenna cable and the corbel hole
with electrical duct seal or as required to prevent infiltration
into the manhole.
Note: Do not connect the antenna cable to the monitor
until after installing the SIM card (when applicable).
INSTALLATION RING
ULTRASONIC DEPTH SENSOR
PEAK COMBO SENSOR
FLOW
SURFACE COMBO SENSOR
OR
ANTENNA
CABLE CHANNEL
CORBEL
ANTENNA CABLE
TRITON+ MONITOR
TM
