Communication 3-21
2. Wrap rubber stretch tape around the entire cable connection,
extending onto the cable approximately 2 inches (50 mm)
beyond the connection with the antenna cable.
COAXIAL STRETCH TAPE
ANTENNA CABLE
TRITON+ MONITOR
ANTENNA PORT
Antenna Cable Connected to Antenna Port on Monitor with Stretch
Tape Properly Applied
3. Carefully coil and secure the remaining slack antenna cabling
as necessary. Slack enables the technicians to remove the
monitor from the manhole for maintenance or service activities
with the antenna still connected.
Note: Remember to avoid bundling the antenna and
sensor cables together! This can significantly diminish
antenna and sensor signal strength, disrupting
communications and limiting sensor accuracy. In addition,
avoid kinking and bending the cables when coiling to
prevent signal loss and damage to the cables and
corresponding equipment.
