User’s Manual
10
ID Button
If a DVR System ID is set to 0, the infrared remote control will control that DVR without any
additional operations. (Refer to the System Information setup screen in this chapter for further
information on setting the System ID.) If the system ID is 1 to 16, you must to press the
ID button
and then press the number button (1 to 16 (+10 & 6)) in order to control that DVR. If the System
ID of two or more DVRs is set to 0, those DVRs will react to the infrared remote control at the
same time.
Camera Buttons
Pressing the individual camera buttons will cause the selected camera to display full screen. Buttons
1 to 4 are also used to enter passwords.
Sequence Button
When in the Live Monitoring mode, pressing the SEQUENCE button displays live channels
sequentially.
Freeze Button
Pressing the FREEZE button freezes the current live screen.
Arrow Buttons
These buttons are used to navigate through menus and GUI. You can also use them to change
numbers by highlighting a number in the menu and using the Up and Down arrow buttons to
increase or decrease the number’s value. These buttons are also used to control Pan and Tilt when
in the PTZ mode.
Pressing the Left and Right buttons moves through screen pages in the Live Monitoring mode
and Search mode.
Menu Button
In the Live Monitoring mode and Search mode, pressing the MENU button displays the menu icons
at the top of the screen. Pressing the button also hides the menu icons. During menu setup, pressing
the button closes the current menu or setup dialog box.
Playback Buttons
y
Rewind: Pressing the button plays video backward at high speed. Pressing the button again
toggles the playback speed from
, and .
y Play/Pause: Pressing the
button plays back video at regular speed. The screen displays
when the DVR is in the Pause mode and the screen displays when the DVR is playing back
video.
y Fast Forward: Pressing the button plays video forward at high speed. Pressing the button
again toggles the playback speed from
, and .
