Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 4 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs
Composite: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1 (Auto Detect)
Video Resolution
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 720x480@60Hz (NTSC), 720x576@75Hz (PAL)
Record Speed
(images per second)
Real-time: 120ips (NTSC), 100ips (PAL) @ 2CIF
Playback Speed
(images per second)
Full Duplex: 120ips (NTSC), 100ips (PAL) @ 2CIF
INPUTS/OUTPUTS
Alarm Input 4 TTL, programmable as NC or NO, 4.3V threshold
Alarm Output 1 relay output, terminal blocks, 1A@30VDC
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45)
Audio Input RCA Input: 1, Line In
Audio Output RCA Output: 1, Line Out
CONNECTORS
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC (Auto Terminating)
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
Audio In 1 RCA connector
Audio Out 1 RCA connector
Alarm Input/Output Terminal blocks
Ethernet Port RJ-45
RS232 Serial Port Two-connector terminal block
RS485 Serial Port Two-connector terminal block
USB Port 2 (USB 2.0)
IR Port 1 Remote Control
STORAGE
Primary Storage SATA hard disk drive
Secondary Storage USB hard disk drive or flash drive
