4-Channel Digital Video Recorder
11
y
Stop: Pressing the button stops playback and enters the Live Monitoring mode.
y Backward: When in the pause mode, pressing the button moves to the previous image.
y Forward: When in the pause mode, pressing the button moves to the next image.
In the Live Monitoring mode, pressing any playback button enters to the Search mode.
Panic Button
Pressing the PANIC button starts panic recoding of all camera channels, and displays on the
screen. Pressing the button again will stop panic recording.
Layout Button
Pressing the LAYOUT button toggles between full screen and quad (2x2) screen modes.
Zoom Button
Pressing the ZOOM button zooms the current image on the screen. A PIP with a rectangle temporarily
displays showing what area of the screen has been enlarged. You can use the arrow buttons to
move the rectangle to another area.
PTZ Button
Pressing the PTZ button enters the PTZ (Pan/Tilt/Zoom) mode which allows you to control properly
configured cameras.
Enter Button
The (Enter) button selects a highlighted item or completes an entry that you have made during
system setup.
Alarm Button
Pressing the ALARM button resets the DVR’s outputs including the internal buzzer during an alarm.
PTZ Control Buttons
While in the PTZ mode, the PRESET buttons are used to save Presets and load a Preset View, the
ZOOM buttons are used to Zoom In and Zoom Out, and the FOCUS buttons are used for Near
Focus and Far Focus.
Back Up Button
Pressing the BACK UP button allows you to copy video clips.
Calendar Button
In the search mode, pressing the CALENDAR button displays the Calendar Search screen.
