209298 - DVE5000 Technical Operation Handbook - CL140042 Page 10 of 110
2.4. REMOTE CONTROL / MONITORING / HPA CONTROL
Remote Control (serial) RS232 / RS485 auto switch by plug insertion
USB For field up-grades
Remote Control (Ethernet) 10/100Mbits/s
IP Address (default) 192.168.0.90
Netmask
255.255.255.0
MAC address 00.1D.65.xx.xx.xx (x is generated from serial
number)
HPA Control RS485 in HPA native protocol
Monitoring Status Ground free contacts – Open = FAIL (H/W
configurable.)
2.5. PERFORMANCE
2.5.1 Baseband:
AUDIO
THD <0.1%
Frequency Response 20Hz-18KHz +/-0.25dB
Crosstalk <60dB@10KHz
Sampling rate 48KHz fixed
Minimum bit rate
128Kbits per stereo channel
Signal to Noise >65dB
VIDEO (composite for SD only)
Differential Gain <1%
Differential Phase <1 degree
Luma Bandwidth 5.5MHz
Luma Non-Linearity 1%
Chroma Non-linearity 1%
Signal to Noise >56dB
2T pulse response <1%K
K- pulse – bar 1%
Kbar 0.05%
Y/C timing 10nS
Jitter +/-2.5nS (1 field)
Encoding Delay – standard (SD) <200mS*
Encoding Delay – Low (SD) <80mS option*
Encoding Delay – (HD) <80mS *
* does not include IRD / decoder
