209298 - DVE5000 Technical Operation Handbook - CL140042 Page 9 of 110
2. SPECIFICATION
2.1. PHYSICAL
Dimensions 1RU ½ width chassis x 350 mm deep
Weight 1.7 Kg approx.
Power connector 3 Pin IEC plug with dual fusing
AC Supply 90-264V AC 47 to 63 Hz @ <60 VA
Temperature Range 0 to +50°C operating –20 to +80°C storage
Humidity 90% max non condensing
RS232/485, Status, HPA
control
15Way D-type Female
Ethernet control RJ45
USB Ports Type A
Video, ASI, 70MHz
connections
BNC 75R
L-Band RF out, L-Band RF
monitor
N-Type 50R
L-Band RF combiner TNC 50R
Audio inputs 15way D-Type Male (breakout to 4 x XLR
provided)
2.2. INPUTS
CVBS PAL / NTSC composite 1Vp-p 75R
SDI (option) PAL / NTSC serial digital video to ITU-R
BT.656 / ANS I/ SMPTE 259M @ 270Mb/s.
8 channels (4 stereo) embedded audio
supported (only 4 compressed) – 75R
HDSDI (HD only) To SMPTE 292M @ 1.485 Gbit/s
ASI (re-mux option) 75R to ISO / IEC 13818-2 188bytes
AUDIO Digital Digital – AES/EBU 110R balanced to IEC
60958
L-Band Combiner 6dB+/-1dB passive coupler into main L-
Band output
2.3. OUTPUTS
L-Band 50R, 950 – 1750MHz +/-0.75dB, -5dBm 35dB
control or +5dBm 40dB control; front panel
selectable
L-Band MONITOR 50R, 20dB+/-3dB less than main L-Band output
ASI 75R, to ISO/IEC 13818-2 188bytes constant rate.
70MHz
75R, 70MHz (tuneable 52 – 88MHz dependant on
symbol rate / bandwidth)
DVBS / S2 0dbm to -12dBm
DVB-T -5dBm to -15dBm
DC on L-band 17V @ 1A max.
10MHz Reference on L-band FACTORY OPTION 0dBm min.
FSK for HPA control on L-band 0dBM <2MHz
