209298 - DVE5000 Technical Operation Handbook - CL140042 Page 11 of 110
2.5.2 A/V Compression:
SD 4:2:0 Main Profile @ Main level 1.0 – 15 Mbits/s constant rate
(I & P frames only) (minimum dependant on FEC)
Option
SD 4:2:2 Profile @ Main Level
(I & P frames only)
1.0 - 50 Mbits/s constant rate
(minimum dependant on FEC)
HD (option) 4:2:0 Field / Frame
Encoded (Frame only in DVBS
modes)
4.5 – 80Mbits/s
HD (option) 4:2:2 Field / Frame
Encoded (Frame only in DVBS
modes)
4.5 – 80Mbits/s
(I & P frames only)
Audio, total of 8 channels (4 pairs)
Audios A & B
MPEG Layer 2
MPEG Layer 1
Audio A & B rates 128Kbs / 160Kbs /192Kbs /
224Kbs / 256Kbs / 320Kbs /
384Kbs / 448Kbs (layer 1 only)
Linear PCM / Dolby Pass thru’
2.4Mb/s
Audios C & D (embedded only) Linear PCM / Dolby Pass thru’
2.4Mb/s
2.5.3 Video Formats:
The following video encoding formats are supported depending on the purchased licence.
Those shown in bold are supplied as standard.
